Larsen Streetscape FBC Eco Permeable Bedding is specifically formulated to exceed the performance characteristics set out in BS 7533-101 (Code of Practice for the Structural Design of Pavements Using Modular Paving Units), Clause 5.4, Table 9.
FBC Eco Permeable is ideal for pavements constructed with clay, concrete or natural stone paving units.
Eco – Reduced Carbon.
FBC Eco Permeable is equivalent to the carbon absorbed by growing two trees for 10 years or by not driving a car for 313 miles per tonne of product used.
Test | BS 7533 Type 35 | Larsen FBC ECO Permeable | Complies |
|---|---|---|---|
Compressive | ≥35 MPa | 42.5 MPa | YES |
Flexural | ≥4.5 MPa | 6.5 MPa | YES |
Modulus | 18,000 ± 3,500 MPa | 16,009 MPa | YES |
Shrinkage | ≤0.09% | 0.03% | YES |
Permeability | ≥5 × 10-5 | ≥5 × 10-5 | YES |
Packaging:
25kg bag
48 bags per pallet
1.2t Weatherproof Bulk Bags:
Dry powder supplied in 1.2t weatherproof bulk bags on pallets for larger projects where 25kg bags are not practical.
